Description

Bronze eye bolts are hardware fastener with a threaded shank and a looped, circular eye at the opposite end. The eye is typically used as an attachment point for connectors, cables, or other fittings, allowing for easy connection and secure anchoring in various applications.

Key features of Bronze eye bolts include:

  • Material: Bronze eye bolts are made of Bronze such as C955,C956 and other high strenght copper alloys. Bronze offers excellent corrosion resistance, making these eye bolts suitable for outdoor and marine applications where exposure to moisture or harsh environmental conditions is a concern.

  • Threaded Shank: The shank of the eye bolt is threaded, allowing it to be securely screwed into a pre-drilled hole or threaded receptacle, providing a strong attachment point.

  • Eye Design: The eye portion of the bolt is circular and closed, forming a loop through which ropes, cables, or other connectors can pass. Some eye bolts may have a welded or forged eye, ensuring greater strength.

  • Size And Load Capacity: Bronze eye bolts are available in various sizes, with load capacities specified for each size. It is crucial to select the appropriate size and load capacity based on the intended application and the expected loads.

Bronze eye bolts find use in a wide range of industries and applications, including marine, outdoor, construction, rigging, and lifting operations. However, it’s important to note that the suitability of bronze eye bolts depends on the specific environmental and load conditions.

Standard

Customized and DIN 444 & 580

Sizes

Bolts From 3mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 16, 1/8, 5/32, 3/16, 1/4, 5/16, 3/8, 1/2, 3/4, 1 inch, M3, M4, M5, M6, M8, M10, M12, M16, UNC, UNEF, UNC, BSW, mm, in, thread size and up to 100 mm in length.
